Summary
Control silicone keypad rib thickness ≤60% of wall, add relief pockets, use texture, and run DFM reviews. FromRubber helps eliminate sink marks before tooling.
You've just received a batch of high-gloss silicone keypads. Under the inspection light, you spot faint, water‑ripple shadows or tiny dimples right in the center. No matter how much you polish, these "ghost marks" won't disappear—destroying the premium look of your product.
Even worse, this defect usually only shows up after tooling trials. The mold is already cut, the cosmetic surface is polished, and now you're facing costly rework or scrapping the mold entirely. FromRubber’s engineering team encounters this exact frustration on a weekly basis during DFM reviews—often because the designer never considered how ribs affect the outer surface.
Technical Analysis
This defect is known as a sink mark—common in injection-molded plastics but equally prevalent in silicone elastomers. The usual culprit? Ribs (reinforcing ribs).
Designers often add ribs to the underside of keypads to increase strength or achieve a certain height. The intent is good, but if the rib dimensions aren't controlled, they leave a permanent scar on the visible surface.
How it forms: During vulcanization, heat travels from the mold wall into the material. Thicker sections—like the root of a rib where it meets the main wall—cool and cure slower than the surrounding thin walls. While the thin areas solidify, the thick section is still shrinking. This "lagging shrinkage" pulls the already‑hardened surface inward, creating a microscopic depression. On a glossy surface, even a few microns of depression cause irregular light refraction—visible as a water‑ripple shadow.
FromRubber terms this the "shrinkage stress traction effect" and emphasizes that the severity of a sink mark has an exponential relationship with the rib‑thickness‑to‑wall‑thickness ratio—not linear. Increasing the ratio from 60% to 80% can make the sink mark 3–4 times more visible.
The Golden Rule of Rib Design
The root thickness of a rib should generally not exceed 2/3 of the main wall thickness. This is the safety threshold established by FromRubber over years of practical experience.
Additionally, rib height matters. Excessive rib height causes poor venting, leading to short shots or air traps. FromRubber recommends a rib height‑to‑thickness ratio of ≤ 5:1, with an R‑angle fillet (R0.2–R0.5) at the top to reduce stress concentration.
The Multi‑Rib Junction Problem
When multiple ribs intersect (e.g., cross‑ribs or grid‑ribs), the material accumulation at the junction is several times greater than a single rib. In these cases, even if each individual rib is at 60% of the wall thickness, the junction can still produce severe sink marks. FromRubber’s solution is to add "material‑relief pockets" or "core‑out holes" at the intersections to disperse the accumulated material and avoid localized thickness.
Real‑World Case Studies
High‑end audio volume knob – Mirror‑finish surface required. The designer set a 2 mm wall thickness and a 2 mm cross‑rib thickness.
Attempts to adjust curing parameters failed. FromRubber diagnosed it using mold‑flow analysis, which showed the junction material accumulation was 2.3× the average wall thickness—far beyond the critical limit.
Fix: Ribs were thinned to 1.2 mm (60% of wall), a circular relief pocket was added at the junction, and a fine MT‑11000 texture was applied to the surface. Sink marks vanished completely—but the client paid extra rework fees and lost three weeks.
Wearable device keypad – The client submitted their 3D CAD to FromRubber’s DFM team during the design phase.
FromRubber provided three modification options. The client chose to add a "relief groove" at the rib root. This eliminated the sink risk without changing the wall thickness or surface finish.
Result: First‑shot samples passed with zero cosmetic defects. Production started on schedule with zero rework.
Actionable Solutions – The FromRubber Checklist
To achieve a flawless cosmetic surface, run through this checklist before cutting any steel:
- Thin ribs to a safe thickness – Ensure rib root thickness ≤ 60%–70% of the main wall. The optimum target is 50%–60%—the safest range validated by FromRubber’s extensive database.
- Add relief pockets at multi‑rib junctions – For cross‑ribs, grid‑ribs, or circular ribs, always incorporate core‑out holes or relief grooves at intersections. Depth should be 30%–50% of the wall thickness.
- Apply mold texture to the cosmetic surface – If a thicker rib is unavoidable (e.g., for ultra‑high strength requirements), use EDM texturing (MT‑11000 to MT‑11030) on the corresponding external face. The roughened surface effectively breaks up light refraction and hides sink marks.
- Run Moldflow simulation – For mirror‑finish or high‑gloss parts, FromRubber recommends performing a Moldflow analysis before tooling to simulate material flow and curing shrinkage, identifying high‑risk zones early.
- Control rib height‑to‑thickness ratio – Keep the ratio ≤ 5:1, and add an R0.2–R0.5 fillet at the rib top to reduce stress concentration.
- Submit a DFM review – This is the most critical step. Before any tooling starts, send your 3D CAD to FromRubber’s engineering team. We provide a comprehensive DFM report within 24 hours—covering rib thickness, sink risks, venting design, draft angles, and more. We help you eliminate problems at the drawing stage.
The Bottom Line
Sink marks—those persistent "ghost shadows" on your silicone parts—are fundamentally a manifestation of stress induced by uneven material shrinkage. The cause is clear (localized material accumulation), and the solution is straightforward (control rib geometry, disperse accumulation, and use surface texture if needed).
However, the key is to recognize this risk before tooling begins and actively design it out. FromRubber brings decades of hands‑on experience in silicone keypad structural reviews and mold design. We maintain a complete DFM review system and advanced mold‑flow simulation capabilities.
